High Speed Textile Cutter CNC Automatic Fabric Cutting Machine for Garments Sofa
Jinan Kang Jia CNC Equipment Co., Ltd.- Voltage：110V , 220V , 380V
- Power Source：Electric
- Automatic Grade：Automatic
- Warranty：1 year
- Certification：CE, ISO
- Effective Cutting Area：2500mm*1600mm
Base Info
- Cutting Thickness：0.1-50mm
- Cutting Accuracy：0.1mm
- Cutting Speed：Max. 1500mm,S
- Material Fixed Mode：VAC-Sorb
- Location Mode：Infrared Laser
- Fan Power：9kw
- Drive Servo Motor：Panasonic , FUJI , Yaskawa Optional
- Support File：Dxf & Plt
- Transport Package：Wooden Box
- Specification：3600m*2500*1315
- Trademark：kangjia
- Origin：Jinan China
- HS Code：8461500090
- Production Capacity：100 Sets , Month
Description
Main Parts:S/N Items Brand Details
1
Servo Motor
Panasonic (Japan)X: 400w (width) Y: 750w (length) Z: 100w (up and down) W: 100w (rotary)
2
Linear Guide Rail
PMI (Taiwan, China)Large loading capacity, high transmission accuracy & high transmission speed
3
Ball Screw
TBI (Japan)High precision and minimal reverberation gap
4
LCD Control Panel
Kangjia (China)Size: 7 inch Resolution: 800x480 Voltage: 10.5-28VDC
KWH: 1A@12VDC, 450mA@24VDC
5
Vacuum Adsorption Platform
Kangjia (China)The platform is made of 6-series aluminum alloy, and the built-in honeycomb support structure is made of 7-series aviation aluminum, which ensures that the platform will not be deformed for a long time
6
Underlay
Ammeral Beltech (Netherlands)The underlay is made of high density polyester fiber. Its life time is longer. It provides great cutting resistance. This cover not only protest blades well, but also provides wonderful breathable channel to guarantee good hold-down.
2.5mm or 4mm can be chosen
Exhibition
Packing and delivery
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
Our service
Before sales:
1. 12 months warranty for the whole machine.
2. Technical support by phone, email or WhatsApp / Skype around the clock.
3. Friendly English version manual and operation video CD disk.
4. If necessary, the fields service can be provided.
FAQ
Q: 1. How can I choose a suitable Knife cutting machine?
A: Please provide us some info, then we can recommend you the suitable machine:
1)What materials are going to cut? Are they rolled or not? Breathable or not?
2)What's the largest size of original materials?
3)What's the thickness of materials?
4)Excepting for cutting, do you need more functions, like drawing, punching holes, scanning, feeding, CCD camera, etc.?
Q: 2. Can you design a machine for me depending on my requirements?
A: Of course, we will give our professional suggest and discuss details with you for the machine which matches all the requests with best cost performance.
Q: 3. What should I do if the machine has any problem in future?
A: We supply online/phone technical support and door to door service. Anything confuse or not goes well, pls contact us in the first time.
Q: 4. What's the warranty policy?
A:Standard warranty is 12 months upon delivery.
Main parts are free of charge(except consumable parts) when problems happened because of quality problem during this period.
Problems caused by wrong operate will also well-solved, but not for free.
We also supply life long after-sales service. No matter when, you can count on our best service for your machine.
Q: 5. If I don't know this machine before, how can I operate it?
A: We supply face to face training and provide operating video, user manual, and telephone calls to help.
It's easy to learn, one inexperience people can learn it within one day.
