Medcal Electric Gynecological Table Obstetric Examination Couch EL3603
Shanghai MedEco Industry Co., Ltd.- Material:Metal
- Type:Manual Bed
- Folded:Operating Table
- Using Ambient:Hospital
- Certification:CE, FDA, ISO13485
- Packing:149 X 74 X 69cm (Heavy Carton)
Base Info
- Model NO.:EL3603
- N.W./G.W:80,90kgs
- Adjustable Height:64.5cm–106cm
- Transport Package:Standard Export Packing Box
- Specification:CE
- Trademark:MEDECO
- Origin:China
- Production Capacity:5000PCS,Year
Description
Basic Info.
Model NO. EL3603 N.W./G.W 80/90kgs Adjustable Height 64.5cm–106cm Transport Package Standard Export Packing Box Specification CE Trademark MEDECO Origin China Production Capacity 5000PCS/YearProduct Description
Medcal Electric Gynecological Table Obstetric Examination Couch EL3603Description
This Electric gynecological table adds a extra extension at EL36 item, more comfortable for leg rest. It provides an extra function, same as a useful examination table.
The Electric gynecological table use dual Taiwan professional medical DC motor putter, low noise, stability and strong. Use For gynecological examination, liver and intestine examination and so on.
Specification :
1. Two electric motors, standard supports "Timotion" brands for Hi-Lo & middle lifting.
2. This product have two retractable wheels and two big wheels.
3. Lift for height variation and middle section by double foot switches.
4. Adjustable backrest featuring double gas struts, angle adjustable from 0°to +80°.
5. Adjustable seat section featuring one motor, angle adjustable from 0°to +20°.
6. Adjustable Up and down side rails (pair) to protect patients.
7. Accessories: Up and down side rails, Stainless steel plate, leg supports, Extra extension
8. Electric gynecological table able to lift up to 225kgs working weight from its lowest height.
9. Retractable castors 75mm for excellent mobility and safety.
10. Electric gynecological table make a new design for triangular parts.
11. Fire/stain/mildew/oil/water/wear resistant Med PVC available in 9 kinds of colors.
Standard Options
1. Extra 2cm foam thickness for upholstery.
2. Hand switch is available.
3. Paper roll holder is available
4. Contact us for more available optional.
Dimensions
Upholstery Length: 185cm
Backrest Length: 90cm
Seat Section Length: 46cm
Upholstery Width: 60cm
Foam Thickness: 5cm
Foam Density: 36g/m2
Open: 139 x 60 x (64.5-106)cm
Adjustable Height: 64.5cm-106cm
Packing: 149 x 74 x 69cm (Heavy carton)
N.W./G.W.: 80/90kgs
20GP/40GP:24/68pcs
